HEPA Concrete Dust Collector

HEPA Concrete Dust Collector

Ensuring safe operation and air quality are the main goals of the HEPA concrete dust collector, SF-D1/D2/D3 110 / 220 V industrial dust collection system are specially used for grinding and polishing concrete floors.

Application

Pneumococcus is caused by long-term inhalation of large amounts of silica and other dust. The dust stays in the bronchi-oles and alveolar for a long time, and even if it leaves the dusty workplace, the lesions will continue to develop.

According to the Ministry of Health data, the incidence of pneumococcus is the highest in occupational diseases. According to the data, by the end of 2010, the proportion of cases was as high as 90.21%, and the mortality rate exceeded 20%.

Technical Specification

Advantages

H13 HEPA filter which conform to OSHA

HEPA filter for SF-D1

The filter area of the first grade filter is 1.7 m², and the H13 filter area is 1.2 m². Each HEPA filter is independently tested and certified. SF-D1 secondary filtration can separate fine dust with efficiency> 99.99%@0.3μm, ensuring that your working space is a clean and safe environment. SF-D1 is recommended for small grinders such as HW-G1 concrete floor edge grinder and handheld concrete grinders.

HEPA filter for SF-D2

The filter area of the first grade filter is 3.0 m², and the H13 filter area is 2.4 m². H13 filter is the final stage. Each HEPA filter has been individually tested and proven to have a minimum dust removal efficiency of> 99.99%@0.3μm, meeting new silica requirements.

HEPA filter for SF-D3

The filter area of the first grade filter is 4.2 m², and the H13 filter area is 3.6 m². With 3 pieces of Ametek large motors, SF-D3 has enough power for any medium or large size concrete floor grinder, concrete floor scarifier, floor shot blasting machine, for suction the concrete floor dust. Certified HEPA filters (0.3 microns) reach 99.99% to ensure that the vacuum exhaust is absolutely dust-free. SF-D3 comes with a complete tool kit including hoses, rods and floor tools.

The thickness of the HEPA concrete dust collector barrel is 1.5 mm

In order to reduce the manufacture cost, common concrete dust extractors usually makes the barrel 1.0 mm thickness. However, HONWAY concrete dust extractors makes barrel 1.5 mm thickness. 1.5 mm is stronger and more durable for preventing rust and corrosion. Neither dust nor liquid in the barrel will leak.

Continuous bagging system ensures quick and dust free bag changes

HONWAY industrial dust collector adopts a unique continuous bagging structure-continuous bagging, which is convenient for loading and unloading. It is folded by a tubular plastic bag and can be continuously pulled. The length of each set is about 22 meters, which can be used 25 times. The dust collection bag is made of polyethylene (PE), polyethylene film, light and transparent, and has the properties of moisture resistance, oxygen resistance, acid resistance, alkali resistance, general air tightness, and excellent heat seal ability.

Efficient jet pulse filter cleaning

The two-stage filter unit can effectively reduce the burden on the filter, which no need for automatic pulse back flushing of compressed air. After a period of use (4-8 hours), clean the dust with the jet pulse filter cleaning system. HONWAY’s unique cleaning system effectively cleans the dust left in the filters. It is economical and practical, and easy to operate.

Filter building block

Considering that the amount of dust generated by concrete floor grinding is very large. The common dust extractors have the problem of filter plugging. SF series HEPA concrete dust collector uses the structure of a pre-HEPA filter + two-stage H13 filter: the two filters work step by step, so the filter area is larger than the only one filter. Two filters greatly reduces the filtering speed, dust ‘s adsorption force on the filters. With the jet pulse filter cleaning, the two filters can be cleaned easily and prevent clogging problems.

The particle size of dust which is produced by floor grinding and polishing is very small (as small as 1 μm). For most common industrial dust collector in the market now, the dust are easy to come out (the outlet of the fan muffler carry very small dust particles). HONWAY industrial concrete dust collectors configure two high-efficiency levels of filters (filtration accuracy reaches 0.3μm) The first-stage filter unit is HEPA filter, with coated with PTFE, TORAY ,made in Japan, and the filtration accuracy is more than 99.5%. The second filtration accuracy is 0.3μm particle size. The filtering accuracy is more than 99.99%, which has a good removal effect on PM2.5 and effectively rejects dust penetration.

In normal use, the service life of the first-level filter is about 0.5-1 year. Replace it according to the actual use and maintenance.

The secondary filter element can be cleaned once every 1-2 months according to the actual use, and the normal service life is about 2 years.

Quick Connector

SF HEPA concrete dust collector series air inlet adopts stainless steel 316 quick connector at the connection of PU hose. Quick connector is one that can connect or disconnect pipes without tools. When the dust extractor and floor grinder are used for a while and needs to clean, the air inlet needs to be disassembled. Installing this quick connector at the air inlet can more easily remove the filter for dust cleaning operation.

Schneider Circuit Breaker

The start and stop of the motor adopts the internationally famous brand- Schneider, circuit breaker, with thermal overload and short circuit protection.

110 / 220V single phrase industrial concrete dust collector machine is available.

Each motor is independently controlled, for on/off. The available voltage is 110 V or 220 V, single phrase.

Caster

There are 4 swivel casters installed at the bottom of the concrete dust collector machine body, each bearing 130 KG. The wheel body is made of super polyurethane (PU), which has excellent shock absorption, abrasion resistance and oil resistance. It can move freely, and is very smooth between rolling, which would not hurt and scratch the floor.

Noise

In terms of noise, in a room with a normal indoor environment of 30 dB. The working noise of the dust extractor is acceptable as it is in the range of 70-80dB, which is relatively low noise level of industrial concrete dust collector.

Jet Pulse Filter cleaning technology
